STANDARD FEATURES
- KOHLER Co. provides one-source responsibility for the generating systems and accessories
- The KOHLER Diesel Powered generator set and its components are prototype-tested, factory-built, and production-tested
- A three-year limited warranty covers all systems and components. Five- and ten-year extended warranties are also available.
OTHER FEATURES
- Controllers are available for all applications
- The low coolant level shutdown prevents overheating (standard on radiator models only)
- Integral vibration isolation eliminates the need for under-unit vibration spring isolators
- An electronic, isochronous governor delivers precise frequency regulation
- Multiple circuit breaker configurations
- Hurricane-rated enclosures available; 186 mph wind load rating on sound aluminum enclosure
ALTERNATOR FEATURES
- The pilot-excited, permanent-magnet (PM) alternator provides superior short-circuit capability
- NEMA MG1, IEEE, and ANSI standards compliance for temperature rise and motor starting
- Sustained short-circuit current of up to 300% of the rated current for up to 10 seconds and enables down stream circuit breakers to trip without collapsing the alternator field
- Self-ventilated and drip-proof construction
- Brushless alternator with brushless pilot exciter for excellent load response
